nvr8canale
New product
NVR 9 Canale Full HD si 4K Network Video Recorder 4K/1080P/960P/720P Onvif HDMI SATA USB
Warning: Last items in stock!
Availability date:
Sistem de operare: Embedded Linux / Procesor 3520D principal
Funcția sistemului de resurse Pentaplex: live, înregistrare, redare, backup si acces de la distanță
Interfața de operare 16-bit true color cu meniu grafic pentru interfață de operare, suport de operare cu ajutorul mouse-ului
Standarde Video PAL 625 linii, 50 f / s; NTSC 525 linii, 60 f / s
Compresie video H.264, H.365
Rezolutii: D1; VGA: ; HDMI
Înregistrarea video 4k/2k/1080P / 720P / 960H / D1 / HD1 / CIF / QCIF
Intrare vidio (IP) 9 * 1080P / 9 * D1
Suportă functia detectare miscare (depinde de calitatea camerei ip)
Compresie Audio G.711a
Mod de înregistrare: Manuală> Alarmă> Dinamic> Sincronizare
Redare 9 * 1080P / 9 * D1
Mod de căutare: Ora / Data, Alarma, Motion Detection & căutare exactă
Backup:Descărcare / flash stick / USB / SATA
Interfață video de intrare (BNC) N / A
Video de ieșire VGA ieșire 1CH, 1CH HDMI
Interfață Net RJ-45 10M / 100M
Control PTZ N / A (Operate în software-ul CMS sau interfact Web)
Interfață USB Port 2 * USB2.0 pentru mouse-ul și de hardisk usb
Hard Disk-1 port SATA (max 1 x 4T)
Alimentare 12V / 2A
Dimensiune 210x 200 x 40 mm
ONVIF Standard 2.0
PACHETUL CONTINE:
(1) 9CH NVR
(1) Alimentator priza 220v - 12v
(1) Manualul de utilizare
SKU Means:
Face Record/Face Detection/Face Playback
Record every face that appears on the lens, without missing any details.
Please note, to work human detection and face detection, You need to have compatible ip camera!
Compatible cameras: (Only) Netip Protocol Face IP Camera
Advanced H.265++ Video Compression
H.265 (HEVC) doubles the coding efficiency compared with its predecessor H.264. That means H.265++ video saves around 70% of the bit rate at the same quality of coding.
Motion Detection & Email Alert/Record
when motion is detected, the NVR can send email or start record to the hard disk without missing any important events.
4K Super HD Resulution
4K NVR provies crystal-clear images and videos with 3840x2160P HD resolution.
You will see all details that happens at your surroundings.
Product Material, Size
Plastic Case, built-in main Board
20x20x4CM
Description of applicable cameras
One PCS HDD Support
Support 3.5CH HDD
Orgional Newest HDD Recommend
TOSHIBA, Seagate, Western Digital HDD
Others brands HDD will not work.
Recommend use the Security HDD, not PC HDD
Suitable for multiple environments
Easy remote access Anytime anywhere
P2P technology supports remote access on the mobile device,Just intall the APP on your phone by scanning the QR cade or storing from the APP View the camera remotely anytime, any where. PC use the www.xmeye.net to visit the camera.
Features :
RTSP Function: RTSP Must work with Netip Protocol and Same Local internet, Onvif and Thired items all not support
Our NVR RTSP function only support TRSP Visit the NVR, not support ADD any other cameras.
With H.265 High efficiency Video Compression
With unique time screen in front of the panel, and displays recorder.
Support Symbian S60V3/V5, Windows Mobile, Iphone, Android,, Blackberry and so on.
Support 1*HDD( 8TB), with 2*USB2.0 for backup, burning, upgrading operation
Stronger network service. support IE browse and CMS software
Build-in org,dyndns.net,oray.net and myq-see.com free DDNS dynamic domain name
Built-in own free DDNS Domain Name Server:
With HDMI-Compatible, Support 4K Output
Support P2P cloud functions
System | Model | 32CH | 16CH | 10CH | 9CH | |
Chip | NOVA | Mstar | Mstar | XM | ||
Operating System | Embedded Linux | |||||
System resources | Simultaneous multi-channel real-time recording, playback, network operation, USB backup | |||||
Material | Case | Plastic | Plastic | Plastic | Metal+Plastic | |
Interface | Operator interface | 16-bit true color graphic menu operation interface, support mouse operation | ||||
Preview | 1/4/8/9/16/25/32 | 1/4/8/9/16 | 1/4/8/9/10 | 1/4/8/9/10 | ||
Video | Video input (IP) | 32CH*4K | 16*4K | 10*4K | 9*4K | |
Video compression | H.265/H.264 | |||||
H.265 Require | H.265 Must be the same program Item, or not work. | |||||
Display quality | Max 4K | Max 4K | Max 4K | Max 4K | ||
Playback quality | Max 4K | Max 4K | Max 4K | Max 4K | ||
Motion Detection | Support | Support | Support | Support | ||
Face Detection | Support | Support | Support | Support | ||
Face/Human Compatible cameras: (Only) Netip Protocol Face IP Camera Please note, to work human detection and face detection, you need to have compatible ip camera! We have recommend IP camera as below: Normal 4MP 5MP 8MP Face camera link: Better IMX335 IMX307 Face camera link: | ||||||
Human Detection | Support | Support | Support | Support | ||
Decode | 4K 8MP/5MP/1080P | |||||
VR | Unsupport | |||||
Motion detection | Support(depend on camera) | |||||
Recording mode | Manual>Alarm>Dynamic Detection>Timing | |||||
Local payback | Max 4K | Max 4K | Max 4K | Max 4K | ||
Record & playback | Search mode | Search by Time/Calendar/Event/Channel | ||||
Record storage,usafeqlo | HDD,Network | |||||
Backup mode | Network backup, USB hard disk, USB burner, SATA burner | |||||
Video output | 1ch VGA,1ch HDMI-Compatible HD output | |||||
Audio I/O | 0/0 | |||||
External interface | 3G/Wifi | 32CH Support | 16CH Support | 10CH Support | 9CH Not Support | |
10CH 16CH Please ask seller send firmware Wifi function | ||||||
Network interface | 1*RJ45 10M/1000MBPS | 10/100MBPS | ||||
USB interface | 2*USB2.0 ports (Not support the keyboard) | |||||
HDD | 1* SATA(Up to 14TB for each disk) | |||||
ESATA | Not Support | |||||
Audio Out | 1 Channel | |||||
Third Protocol | Support Some (Support Most of Camera, but if you use Reolink,HIK,Dahua cameras, please ask your camera seller weather can support Xmeye nvr .) | |||||
Power supply | 12V/2A | |||||
Other | Power Consumption | <10W(Without HDD) | ||||
Work environment | Temperature:0℃ -55℃ , Humidity:10%-90%RH , Atm:86kpa-106kp | |||||
Dimension | L255*W245*H42mm | |||||
Weight | A total of about 920g | |||||
Model | 1032/16/10/09R-KL |
Wifi Adapter is not include, if you need, you can Press the photo as below to buy:
(Only 9CH 16CH 32CH board support wifi adapter)
New Style Menu
